The Asse 1022 Dual Check Valve is a space-saving, code-aware solution for potable water backflow protection. It helps prevent contaminants and corrosive substances, such as carbonic acid, from entering drinking water. Using an approved device helps preserve potable supplies while supporting compliance with local and national plumbing requirements.
Asse 1013
Manufacturers such as Watts produce backflow preventers that meet ASSE performance requirements and certifications. Depending on the model and application, approvals may include NSF/ANSI 61, UL, FM, or similar third-party listings. Those credentials help verify material safety, pressure durability, and overall assembly performance. While some jurisdictions require higher-protection assemblies, the Asse 1022 can serve as a reliable low-hazard option where allowed.
The Asse 1022 Dual Check Valve is valued for its small footprint, simple installation, and low maintenance costs. This guide contrasts Asse 1022 devices alongside higher-protection standards, including Asse 1013. It also covers how to select, install, and maintain units to stay compliant with plumbing codes and industry recommendations.
Understanding Backflow And The Role Of Dual Check Valves
Backflow creates a serious risk because water can reverse direction inside a plumbing system. This reverse movement can introduce contaminants into plumbing and compromise drinking-water safety. Water authorities and adopted plumbing codes require backflow protection to help prevent this kind of contamination.
Two main hydraulic causes lead to backflow incidents. Backsiphonage occurs when supply pressure falls, creating suction that can draw water in reverse. Backpressure happens when downstream pressure exceeds supply pressure and forces water in the wrong direction. Understanding backsiphonage versus backpressure is critical because each may require a specific prevention method.
Residential cross-connections often involve irrigation systems, garden hoses, boilers, and chemical injectors. Commercial facilities may also include booster pumps, closed-loop HVAC systems, process equipment, and similar connections. Without the right device, these connections may become pathways for pollutants or unwanted substances.
Dual check valves, including the Asse 1022 model, are designed for low-hazard protection. They are used where reverse flow might affect taste, odor, or water quality without creating a direct health hazard. An Asse 1022 Backflow Preventer can be a compact solution for approved low-hazard applications described by plumbing codes and water authorities.
Proper device selection and installation are guided by codes and standards. ASSE performance requirements and ANSI-accredited development support product acceptance. Installers should follow local plumbing-code language and relevant guidance, such as the 2018 UPC and AWWA M-14, when applying Asse 1022 devices.
Typical approved uses include residential irrigation, HVAC makeup lines, and some commercial low-hazard cross-connections. When the hazard level is higher, authorities typically require a more protective assembly.
| Problem | Typical Cause | Suggested Protection |
|---|---|---|
| Backsiphonage | Main pressure loss from firefighting, broken lines, or supply interruption | Approved Asse 1022 device where allowed, or an air gap for stricter protection |
| Backflow caused by pressure imbalance | Booster pumps, elevated tanks, or thermal expansion | Asse 1022 for low-hazard; RPZ for high-hazard |
| Risk to potable water quality | Chemical injection, treated boiler water, irrigation additives, or industrial fluids | Assess hazard level; apply Asse 1022 or higher-rated device |
How Backflow Occurs In Plumbing Systems
Backflow is the backward movement of water from any source into the public supply. It may be caused by negative supply pressure, backsiphonage, or excess downstream pressure. Either condition can allow contaminants to enter potable lines and threaten drinking-water quality.
Why Low-Hazard Systems Use Dual Check Valves
A dual check valve uses two separate check mechanisms inside a single valve body. That built-in redundancy helps protect low-hazard cross-connections from reverse flow. Asse 1022 devices meet performance criteria for nuisance-level risks and are common where codes allow double-check assemblies.
Understanding The Asse 1022 Dual Check Valve
An Asse 1022 Dual Check Valve is a compact backflow prevention device used for low-hazard potable-water applications. It uses two independent spring-loaded checks arranged in series. That arrangement helps stop reverse flow and gives the device a second sealing point. It also supports serviceability while reducing contamination risk during pressure changes, brief backpressure events, or short disruptions.
Key Features And How The Valve Works
Spring-loaded check mechanisms help the valve close positively when flow or pressure changes. Many units are built with serviceable internals, replaceable seats, or removable parts. This design reduces maintenance time and lifecycle costs.
Manufacturers offer units in several materials, including bronze, brass, corrosion-resistant metals, and engineered plastics. Available sizes are designed to match common pipe diameters, pressure ratings, and potable-water system requirements.
Compact bodies, service access, and built-in test ports can make installation and inspection faster. An Asse 1022 Backflow Preventer can fit into tight locations where larger backflow assemblies may not be practical. Properly sized models can meet flow demands for common low-hazard applications.
Standards And Certifications Supporting ASSE 1022 Devices
ASSE standards define baseline performance tests, functional requirements, and operating thresholds. Those tests are used to verify dependable operation under defined conditions. Many products exceed these minimums, reducing failure risk and extending maintenance intervals.
NSF/ANSI 61 certification confirms materials are safe for drinking water and helps prevent harmful contaminant leaching. UL/FM approvals can support confidence in durability, pressure resistance, and stress-tested performance. These listings give engineers, inspectors, and installers additional assurance when specifying equipment.
When combined with ANSI-accredited development, these approvals improve the Asse 1022 Dual Check Valve’s acceptance in plumbing codes and project specifications. For project teams seeking verified material safety and tested performance, ASSE 1022 features, NSF/ANSI 61, and UL/FM marks create a strong compliance package.
ASSE 1022 Compared With ASSE 1013, ASSE 1012, And ASSE 1024
This outline compares common backflow protection options to help match device features with risk and code needs. It highlights practical differences between RPZ, double-check, and other dual-check devices used in the United States.
Device selection should start with a clear hazard-level assessment. ASSE 1022 double-check assemblies suit low-hazard services such as irrigation and some HVAC makeup lines. By contrast, Asse 1013 RPZ units are designed for high-hazard cross-connections where contaminants could create a health risk. Asse 1024 applies to reduced-pressure principle devices used where severe contamination risk may exist. Use Asse 1012 standards when specifying certain dual-check products or service-line applications.
How ASSE 1022 Differs From ASSE 1013 And ASSE 1024
ASSE 1022 double-check assemblies use two check valves and shutoff valves to prevent backflow in low-hazard situations. ASSE 1013 RPZ assemblies add a relief valve that vents to atmosphere under certain pressure conditions, creating a higher protection margin. Asse 1024 reduced-pressure principle devices use the same relief concept but apply to a broader set of severe contamination risks.
Testing requirements and procedure complexity vary by device type. RPZ units under Asse 1013 require more rigorous annual and post-event testing with relief valve verification. ASSE 1022 double-check devices require periodic testing of the check mechanisms, generally with simpler procedures than RPZ assemblies.
When ASSE 1012 And Other Dual-Check Standards Apply
Asse 1012 covers requirements for selected dual-check configurations used in low- or moderate-hazard applications. Use this category when local code or the water authority accepts a dual-check style but specifies a different recognized standard beyond ASSE 1022.
Code requirements differ from one jurisdiction to another. Many municipalities that follow the 2018 UPC require ASSE 1013 RPZ assemblies for high-hazard cross-connections. Utilities may allow ASSE 1022 for low-hazard applications or specify Asse 1012-certified dual-check devices for certain service-line uses. Before installation, confirm the required protection level with the local water authority or authority having jurisdiction.
| Device Feature | Asse 1022 | Asse 1013 Reduced Pressure Zone | Asse 1024 Reduced Pressure Principle | Asse 1012 Dual-Check Standard |
|---|---|---|---|---|
| Typical use | Low-hazard irrigation and selected HVAC makeup lines | High-risk contamination protection | Severe backflow hazards needing relief-valve protection | Specific dual-check uses allowed by local authority |
| Relative protection | Low hazard | High hazard | High-protection reduced-pressure level | Low to moderate |
| Relief feature | No | Includes atmospheric relief valve | Includes reduced-pressure relief valve | Usually no relief valve unless required |
| Typical testing | Routine check-mechanism verification | Annual and post-event testing with relief verification | Annual reduced-pressure assembly testing | Inspection frequency set by local requirements |
| Common applications | Low-hazard cross-connections where allowed | Chemical feed and boiler makeup with toxic chemicals | Reduced-pressure protection for severe hazard sources | Specific service uses approved by local code or utility |
| Common code treatment | Often allowed for low-hazard applications | Commonly required for high-hazard conditions | Specified for severe hazard protection | Selected where code or utility language specifically calls for it |
When comparing ASSE 1022 with RPZ assemblies, consider the hazard level, safety margin, and testing burden. RPZ versus double-check decisions depend on hazard assessment, local code, and water authority rules. If requirements are uncertain, follow the higher protection level required by the authority having jurisdiction.
Installing, Maintaining, And Staying Code-Compliant
A correct Asse 1022 installation starts with careful planning. Dual check valves should be installed where they are accessible and oriented according to the manufacturer’s instructions. Leave adequate clearance for service access, testing ports, shutoffs, and unions. This lets certified testers access fittings without unnecessary disassembly.
Use sound piping practices so the installation does not create a new cross-connection risk. Do not place the device where downstream cross-connections can bypass or undermine the protection. Install shutoffs, unions, and drain provisions according to manufacturer instructions and local codes. Make sure unions and test cocks remain accessible for routine service and backflow testing.
Maintenance schedules are set by local regulations and water authority directives. Many areas require annual inspections and backflow tests by certified professionals. Detailed records of service and test results are important for proving compliance during audits and permit reviews.
Certified testers can provide documentation that meets many regulatory and water-authority requirements. Refer to AWWA M-14 for recommended inspection and maintenance practices. Following these guidelines can reduce downtime and detect wear before leaks or failures occur.
Selecting devices with recognized listings can simplify inspection and approval. Products with ASSE approvals and NSF/ANSI 61 installation ratings are often accepted more readily by plumbing inspectors. UL/FM compliance also matters for commercial and fire-protection connections where third-party recognition is important.
Before starting, identify the applicable plumbing code edition and local water authority requirements. Some locations may require an RPZ instead of a dual check. Confirm the permit process and make sure the chosen Asse 1022 installation meets local standards to avoid delays and rework.
Establish a consistent record-keeping routine. Keep manufacturer cut sheets, test certificates, repair invoices, and a location map together. This simplifies future inspections and supports transparent compliance during regulatory reviews.
Where To Buy And Product Selection Guidance
Selecting the right device requires matching pipe size, pressure rating, material, and system demand. Confirm that the Asse 1022 Dual Check Valve matches the pipe diameter and peak-flow requirement. Also compare pressure ratings with maximum working pressure and expected surge conditions.
Material compatibility is a key consideration in potable-water systems. Choose brass, bronze, or NSF/ANSI 61-certified plastics to avoid corrosion or leaching. Review the manufacturer’s chemical-resistance data for local water chemistry.
Certification checks simplify approval and inspection. Make sure the product shows ASSE 1022 compliance and NSF/ANSI 61 certification where required. If the local authority requires UL or FM approvals, verify those markings before buying.
Supplier reputation matters when purchasing an ASSE 1022 device. Authorized dealers can provide genuine products, documentation, and warranty assistance. Installation Parts Supply is a reputable distributor that stocks certified units and can help with model selection.
Warranty coverage and pricing rules can affect the final purchase cost. Review manufacturer warranty limits and any MAP rules that hide prices online. Some suppliers show final pricing only in the cart while still preserving warranty coverage through authorized sales channels.
Choose Materials
- Select an Asse 1022 Dual Check Valve model that matches pipe size, flow rate, and installation layout.
- Use NSF/ANSI 61-certified components for potable-water systems whenever required or available.
- Verify pressure rating and surge tolerance for the Asse 1022 Backflow Preventer.
Trusted Suppliers
- Buy from certified dealers to ensure inspection documentation.
- Choose vendors that offer sizing support and warranty handling.
- Installation Parts Supply often provides certified stock and model guidance.
| Buying Factor | What to Check | Reason It Matters |
|---|---|---|
| Sizing and flow demand | Line diameter, expected flow, and model capacity data | Ensures the device can handle demand without unnecessary restriction |
| Body and wetted material | Brass, bronze, or NSF/ANSI 61-certified plastics | Reduces leaching concerns and supports longer service life |
| Pressure and surge capacity | Manufacturer pressure limits and site surge conditions | Reduces risk of damage during pressure changes |
| Compliance markings | Required approvals for code, utility, or project specifications | Helps inspectors approve the installation more easily |
| Supplier | Authorized dealer, documentation, warranty handling | Reduces risk of counterfeit parts and improves after-sale support |
| Warranty and final cost | Manufacturer warranty details, MAP pricing policies | Protects investment and clarifies purchase cost |
Conclusion
ASSE 1022 double-check valves can be compact solutions for low-risk backflow prevention when approved by the local authority. The Asse 1022 Dual Check Valve uses two spring-loaded checks and materials that meet NSF/ANSI 61 and ASSE standards. This helps reduce contamination risks in irrigation and some HVAC makeup lines.
Correct device selection depends on hazard classification, code requirements, and water-authority approval. Use an Asse 1022 Backflow Preventer for low-hazard scenarios. For high-hazard protection, use ASSE 1013, ASSE 1024, or reduced-pressure assemblies. Proper selection streamlines permitting and improves water-system safety.
To ensure backflow prevention compliance, follow manufacturer guidelines and local plumbing codes. Where applicable, this may include the 2018 UPC, local amendments, and water authority rules. Purchase certified products from trusted suppliers. Confirm ASSE listings, NSF/ANSI 61 certification, and UL or FM approvals when those marks are required.
Correct device selection, precise installation, and regular maintenance are essential. When supported by certified devices and qualified testers, these steps help protect potable water. They also make regulatory acceptance, inspection, and documentation easier. Following these practices helps an Asse 1022 Dual Check Valve or other approved backflow solution perform reliably over time.
